This part of IEC 60068 outlines test Td, applicable to surface mounting devices (SMD).
This standard provides procedures for determining the solderability and resistance to
soldering heat of devices in applications using solder alloys, which are eutectic or near
eutectic tin lead (Pb), or lead-free alloys.
The procedures use either a solder bath or reflow method and are applicable only to
specimens or products designed to withstand short term immersion in molten solder or limited
exposure to reflow systems.
The solder bath method is applicable to SMDs designed for flow soldering and SMDs
designed for reflow soldering when the solder bath (dipping) method is appropriate.
The reflow method is applicable to the SMD designed for reflow soldering, to determine the
suitability of SMDs for reflow soldering and when the solder bath (dipping) method is not
appropriate.
The objective of this standard is to ensure solderability of component lead or termination. In
addition, test methods are provided to ensure that the component body can resist against the
heat load to which it is exposed during soldering.dition 4.0 2015-03 INTERNATIONAL STANDARD NORME INTERNATIONALE colour inside Environmental testing – Part 2-58: Tests – Test Td: Test methods for solderability, resistance to dissolution of metallization and to soldering heat of surface mounting devices (SMD) Essais d’environnement – Partie 2-58: Essais – Essai Td: Méthodes d’essai de la soudabilité, résistance de la métallisation à la dissolution et résistance à la chaleur de brasage des composants pour montage en surface (CMS)
